Main technical parameter：
1 | Laminating width(mm): | 400-1100mm |
2 | Laminating thickness: | 0.012-0.03mm |
3 | Machine speed（m/min): | 236m/min |
4 | Laminating line speed（m/min）: | 236m/min |
5 | Screw diameter（mm）: | 80mm |
6 | Screw length: | 2800mm |
7 | Screw rotate speed: | 100r/min |
8 | Max extrusion : | 130kg/h(single machine） |
9 | Roller length（mm）: | 1200mm |
10 | Mould head width（mm）: | 1300mm |
11 | Widing&unwinding max diameter（mm）: | 1400mm |
12 | Unwiding EPC auto eadge control journey(mm): | ±100mm |
13 | Total power（kw）: | 160kw |
14 | Gas flow m3/min: | 0.6m3/min |
15 | Dimention: | (17.5L×8.5W×3.5H)m |
16 | Machine color: | standard color |
17 | Power: | Three phase 380v+single phase 220v,50HZ |
